include file (
tiams.h
) supplied with the TI-89 / TI-92 Plus SDK, BCD16 has been
defined as
double
, and should be used when coding applications as a reminder
that routines containing floating-point operations may not be portable code.
2.9.4. Floating-Point Representations
All TI BCD floating points are 10 byte objects. The first two bytes in the TI BCD
floating-point format are the mantissa sign and exponent. The mantissa sign is
the most significant bit of that word (1=negative, 0=positive) and the other 15 bits
are a 0x4000 biased exponent, where a value less than 0x4000 represents a
negative exponent, and a value greater than 0x4000 represents a positive
exponent. The memory address of a floating-point data object is the address of
the first byte of the sign/exponent. The decimal point is assumed to be after the
first BCD mantissa digit. The mantissa consists of 16 BCD digits, with digits 15
and 16 always equal to 0 in a
float
.
double and float
Low address High Address
2 bytes MSD 8 bytes LSD
0x4000 biased 1 . . . . . . 15 16
exp and sign 16 digit mantissa (digits 15 and 16=0 for
float
)
Figure 2.2: Internal TI BCD Floating
-
Point Representation
Following are some examples of common floating-point values shown as if
written in 68000 assembly language:
_PI:
.word 0x4000 ; 3.141592653589793
.long 0x31415926,0x53589793
_FPZERO:
.word 0x4000 ; 0
.long 0,0
_FPPT001:
.word 0x3FFD ; .001
.long 0x10000000,0
_FPPTFIVE:
.word 0x3FFF ; .5
.long 0x50000000,0
_FPONE:
.word 0x4000 ; 1
.long 0x10000000,0
_FPNEG1:
.word 0xC000 ; -1
.long 0x10000000,0
_FPTEN:
.word 0x4001 ; 10
.long 0x10000000,0
