Quadrature Encoder (QEI)

bool ROM_QEIErrorGet (uint32_t ui32Base)

void ROM_QEIIntClear (uint32_t ui32Base, uint32_t ui32IntFlags)

void ROM_QEIIntDisable (uint32_t ui32Base, uint32_t ui32IntFlags)

void ROM_QEIIntEnable (uint32_t ui32Base, uint32_t ui32IntFlags)

uint32_t ROM_QEIIntStatus (uint32_t ui32Base, bool bMasked)

uint32_t ROM_QEIPositionGet (uint32_t ui32Base)

void ROM_QEIPositionSet (uint32_t ui32Base, uint32_t ui32Position)

void ROM_QEIVelocityConﬁgure (uint32_t ui32Base, uint32_t ui32PreDiv, uint32_t

ui32Period)

void ROM_QEIVelocityDisable (uint32_t ui32Base)

void ROM_QEIVelocityEnable (uint32_t ui32Base)

uint32_t ROM_QEIVelocityGet (uint32_t ui32Base)

16.2.1 Function Documentation

16.2.1.1 ROM_QEIConﬁgure

Conﬁgures the quadrature encoder.

Prototype:

void

ROM_QEIConfigure(uint32_t ui32Base,

uint32_t ui32Config,

uint32_t ui32MaxPosition)

ROM Location:

ROM_APITABLE is an array of pointers located at 0x0100.0010.

ROM_QEITABLE is an array of pointers located at ROM_APITABLE[9].

ROM_QEIConfigure is a function pointer located at ROM_QEITABLE[3].

Parameters:

ui32Base is the base address of the quadrature encoder module.

ui32Conﬁg is the conﬁguration for the quadrature encoder. See below for a description of this

parameter.

ui32MaxPosition speciﬁes the maximum position value.

Description:

This will conﬁgure the operation of the quadrature encoder. The ui32Conﬁg parameter provides

the conﬁguration of the encoder and is the logical OR of several values:

QEI_CONFIG_CAPTURE_A or QEI_CONFIG_CAPTURE_A_B to specify if edges on

channel A or on both channels A and B should be counted by the position integrator and

velocity accumulator.

QEI_CONFIG_NO_RESET or QEI_CONFIG_RESET_IDX to specify if the position inte-

grator should be reset when the index pulse is detected.

QEI_CONFIG_QUADRATURE or QEI_CONFIG_CLOCK_DIR to specify if quadrature sig-

nals are being provided on ChA and ChB, or if a direction signal and a clock are being

provided instead.

QEI_CONFIG_NO_SWAP or QEI_CONFIG_SWAP to specify if the signals provided on

ChA and ChB should be swapped before being processed.

176 April 8, 2013
