Analog Comparator
COMP_REF_2_26875V to set the reference voltage to 2.26875 V
COMP_REF_2_371875V to set the reference voltage to 2.371875 V
Returns:
None.
4.2.1.7 ROM_ComparatorValueGet
Gets the current comparator output value.
Prototype:
bool
ROM_ComparatorValueGet(uint32_t ui32Base,
uint32_t ui32Comp)
ROM Location:
ROM_APITABLE is an array of pointers located at 0x0100.0010.
ROM_COMPARATORTABLE is an array of pointers located at ROM_APITABLE[6].
ROM_ComparatorValueGet is a function pointer located at ROM_COMPARATORTABLE[3].
Parameters:
ui32Base is the base address of the comparator module.
ui32Comp is the index of the comparator.
Description:
This function retrieves the current value of the comparator output.
Returns:
Returns true if the comparator output is high and false if the comparator output is low.
34 April 8, 2013
