Notice: Keep the parts for the trimmer head together for later use.
Mounting of blade. See Fig3a
1. Fit the holder (7) in the hole of the trimmer gear (9),and the bearing(5) so that is
fastens the axle.
2. Fit the blade (6) and the washer (4) onto the axle.
3. Fit the washer (3) and nut (2). Fasten tightly anticlockwise.
4. Fit the pin(1).
Ensure that the blade is tightly fastened. If unclear ask your local dealer for advice.
7. Changing from brush cutter to trimmer
Dismounting the blade
1. Remove the pin (1) Fit the holder (7) in the hole of the trimmer gear(9),and the
bearing(5) so that it fastens the axle..
2. Remove the nut (2),that fastens the blade.
3. Washer (3), spacer (4) and blade (6) may now be removed.
Notice: Store the parts together for later use.
Mounting of trimmer head. See Fig3b
1. Mount the holder (7) on the trimmer head so that it fastens the axle.
2. Mount the trimmer head by turning it anticlockwise.
3. Fasten the trimmer head tightly before use.
8. Replacement the trimmer cord
Fig.4
1. Stop the engine.
2. Press on each side of the line compartment. The lid may now be removed.
3. Dismount the roll simply by pulling it. Leave the spring (B), on the spool. Remove
any bits of line. Attach 3-4 meters of new line (2,4 mm) and place it double.
4. Fit each end of the line into a hole on the spool. Wind the two ends of line in the
direction of the arrow. Avoid twisting the line. Finally cut the double line at the
middle. Fit the two ends through the line controllers.
Do not overfill the spool!
5. Mount the line compartment in reverse order. First, fit the spring into its position.
Then place the line in the two holes of the line compartment.
6. Finally mount the lid. Make sure that it is fitted securely.
Always make sure that the trimmer head is fitted securely. If in doubt ask your local dealer
for advice.
9. Operation
High grass should always be cut from the top and downwards. In this way you
prevent the grass from being wrapped around the trimmer head and thereby lead to
overheating and damage. If grass and the like is wrapped around the trimmer head
