3. Mounting of safety guard a nd handle
Mount the safety guard using the furnishing and the
screws applied. Make sure that the safety guard
is securely fastened.
The handle must be mounted so that the machine
is in balance. This makes the tool pleasant to us e.
Right handle
Top bracket
Left handle
Screw
Bracket
Safety guard
Plate
M5X25 screws
Bracket below
