10
With the spanner fitted to the outer flange, fit the locking
nut and tighten with the blade spanner in a clockwise
direction.
After the blade is secure, rotate the blade by hand to
ensure the blade is not making contact with any
components of the edger.
Blade wear is expected whenever you use your edger.
Blades wear quite quickly when edging along concrete
paths. This does not effect the efficiency of the Edger
and is expected due to the aggressive abrasion of
concrete on steel.
Edger Blades are not a warranty item! Edger Blades are
available from your local Hardware store or con be
purchased direct from your TEXAS dealer. See details
on the back page of this manual.
Cord Restraint
Fig 7
Your TEXAS EDGER is fitted with a Cord restraint to
prevent the power coble from both being disconnected
and also to prevent excessive strain on the connecting
plugs during use. It is recommended the cord restraint
is used as follows.
Approx. 300mm from the end of the extension Cable,
form a tight loop in the extension cable, and feed the
loop through the square hole in the rear of the handle.
Place the loop over the inner hook in the handle to
prevent the cable pulling back through the square hole.
The extension cable can now be connected to the
edger, with the plug of the EDGER and the socket of
the extension cable hanging free, and not being
effected by any movement during operation.
IMPORTANT. Loose wearing bracelets or similar
jewellery around the wrist should be removed when
using this type of equipment.
Important work information
When a switch is released a short spark may appear
from the engine.
This is not abnormal and should not lead to
worries.
The spark is caused by the braking system that is
build into the product.
Maintenance
• For obtaining the best cutting results the knives
must be cleaned and oiled regularly. Remove dirt
with a brush and oil lightly.
• Use biodegradable oil.
• Clean the housing and other parts with a mild
cleanser and a moist cloth. Never use aggressive
cleansers or solvents.
• Prevent water from getting into the machine.
• Use the blade protection when the machine is
stored.
Disposal
Warning! The product is made of different materials
such as metal and artificial material.
Waste electrical products must not be
disposed of with the household waste.
This tool should be taken to your local
recycling center for safe treatment.
Batteries must be disposed separately and not together
with the machine.
Batteries can also be disposed in most recycling
centers.
Technical data
Engine type : Electric 230V
Power : 1400 watt
Power : 2900 rpm
Starter : Electric
Handle : Adjustable
Handle : Telescope
Working depth : 15, 25, 38 mm
Weight : 6.8 kg
Measured LPA : 82 dB(A)
Guaranteed LWA : 96 dB(A)
Vibration ah : 2.76 mls
2
(front handle)
Vibration ah : 2.50 mls
2
(rear handle)
Warranty claim
The warranty period is calculated from the date of
purchase and is valid for 2 years.
The complaint covers defective performance or material
and malfunction.
Required parts and used working to complaints benefits
are not calculated.
We accept no liability for consequential damages.
Due to continued product development, reserves
TEXAS A/S reserves the right to change / improve the
product without being obliged to change the already
sold models.
