Texas XM Series - User Manual

Questions and Answers

L
Linda AguilarJul 31, 2025
Why is my Texas Lawn Mower engine running irregularly?
- E
  Eugene JamesJul 31, 2025
  An irregular engine performance in your Texas Lawn Mower can stem from several causes: * The spark plug cap might be loose. Ensure it's firmly attached. * The spark plug might be dirty. Inspect and clean it as per the manual. * The gap between the spark plug and the electrode might be incorrect. Check and adjust it according to the manual. * The air filter might be dirty or defective. Inspect and clean the air filter. * There might be evaporation of fuel in the carburettor. Wait a few minutes before attempting to restart. * The throttle cable might be loose. Tighten the throttle cable as per the manual. * There might be dirt in the carburettor. Clean the carburettor.
K
Karen FreemanAug 5, 2025
What to do if Texas Lawn Mower has no ignition spark?
- R
  Rachel BoothAug 5, 2025
  If your Texas Lawn Mower has no ignition spark, it could be due to: * A loose spark plug cap. Ensure the cap is firmly attached to the spark plug. * A damp or dirty spark plug. Check the spark plug for dirt, following the instructions in the manual. * An incorrect gap between the spark plug and the electrode. Check and adjust the spark plug gap, following the instructions in the manual. Alternatively, replace the spark plug. * A dirty or defective air filter. Check the air filter for dirt and clean it, following the instructions in the manual.
M
Michelle WalkerAug 9, 2025
Why Texas Lawn Mower start cable is very tight?
- M
  Makayla ChavezAug 9, 2025
  If the start cable on your Texas Lawn Mower is very tight, it could be due to: * The brake handle not being activated. Activate the brake handle and pull the start cord. * The machine being placed in high grass. Move the machine away from the high grass and repeat the start procedure. Set the height adjustment in the highest position, so that the blade is lifted free of the grass.
T
Timothy BennettAug 13, 2025
What to do if my Texas Lawn Mower does not stop after 5 seconds?
- S
  Susan RossAug 14, 2025
  If your Texas Lawn Mower doesn't stop after 5 seconds, it could be because the engine brake cable runs too tightly. In that case, check and adjust the engine brake cable, following the instructions in the manual.
R
Ryan HaneyAug 18, 2025
Why does my Texas Lawn Mower have insufficient engine revolutions?
- D
  David AlexanderAug 18, 2025
  If your Texas Lawn Mower has insufficient engine revolutions: * The lever might be in the "Choke" position. Set the lever in the "Run" position. * The throttle lever might be set for "Turtle". Set the throttle lever for "Rabbit".
A
Ann StricklandAug 22, 2025
Why Texas Lawn Mower back wheels are not pulling?
- M
  masonlindseyAug 22, 2025
  If the back wheels of your Texas Lawn Mower aren't pulling, it could be due to: * The clutch cable being too tight or too loose. Adjust the clutch cable, following the instructions in the manual. * The ratchets in the rear wheels being worn. Replace the ratchets.
C
Carl MaldonadoOct 27, 2025
What to do if my Texas Lawn Mower will not start when pulling the start cord?
- H
  Heather BarajasOct 27, 2025
  If your Texas Lawn Mower doesn't start when you pull the start cord, there could be several reasons: * The brake handle might not be activated. Make sure to activate the engine brake handle. * The wires might not be connected to the battery. Check that the wires are properly connected from the battery to the motor and start button. * The brake cable might be incorrectly adjusted. Adjust the engine brake cable according to the manual's instructions. * The lawn mower might be standing in high grass. Move it to an area with less grass. * The engine might not be primed. Push the primer 1-3 times before starting. * The choke might be in the wrong position. Adjust the choke lever. * There might be no gasoline in the fuel tank. Check and fill the tank. * The gasoline might be old...

Summary

Safety

Gasoline safety

Guidelines for safe handling and use of gasoline.

Identification of the parts

Mounting

Handlebar and height adjustment: Illustration M2

Mounting the recoil-starter: Illustration M4

Cable Adjustment

Adjusting the drive cable: Illustration A1-1

Adjusting the engine brake cable: Illustration A1-2

Adjusting the throttle cable: Illustration A1-3

Battery (Electric starter)*

Charge the battery before use

Initial charging procedure for the electric starter battery.

Operation

Cutting height adjustment: Illustration F1

How to adjust the cutting height of the mower.

Recoil with primer, illustration F2

Step-by-step guide to starting the engine using the primer and recoil starter.

Recoil with choke, throttle lever illustration F3-A

Electrical starter, illustration F3-B

Recoil with choke, speed lever illustration F3-C*

Stop: Illustration F4

Instructions on how to safely stop the mower and engine.

Oil change

Procedure for changing the engine oil, including frequency and method.

Air Filter

Blade

Inspection of the blade

Removing the blade: See illustration A3

Spark plug

Storage and maintenance

Warranty

Troubleshooting

Difficult to start

Solutions for common starting issues with the lawnmower.

The mower starts, but runs unevenly

The engine will not stop

How to diagnose and resolve issues where the engine fails to stop.

Texas XM Series Specifications

General

Power Source	Gasoline
Engine Type	4-Stroke
Cutting Width	21 inches
Cutting Height	1.25-3.75 inches
Warranty	2 years
Drive System	Rear-wheel drive
Speed Settings	Variable
