Texecom Odyssey X Series User Manual

INS627-8 11/44
1.7 Inserting the Odyssey X1 graphic
(available separately, see chapter 1.3)
Removing the light diffuser1.
Gently flex the two sides of the lid outwards so that the tabs release from the
lid.
Lift the light diffuser upwards to release.
N Please make sure this operation is done in a clean dry environment. where
the diffuser and lid are not likely to be scratched or damaged.
2. Insert the Graphic
Place the graphic face down in the window recess as shown.
