INS627-8 39/44
Physical
Backplate All Models 3mm Polycarbonate
Covers All Models 3mm Polycarbonate/3mm PMMA
Tamper Detection
All models Wall & Inner cover
Lid dimensions (h x w x d)
X3 290mm x 276mm x 58mm
X1 290mm x 186mm x 58mm
Module Dimensions (h x w
d)
287mm x 170mm x 51mm
Packed Weight
Module only (Not X-W) 791g (28oz) approx
Module Ony (X-W) 991g (35oz) approx
X1 Cover 310g (11oz) approx
X3 Cover 613g (22oz) approx
Electrical wired units
Supply voltage 12-16Vdc (13.7Vdc nominal)
Current drain (typical @13.7Vdc
Quiescent 18mA with backlight 58mA
Strobe 100mA
Sounder SAB LC SCB
X-E Models 285mA 160mA 30mA
X-BE Models 325mA 200mA 70mA
X Models 405mA 190mA 30mA
X-B Models 445mA 230mA 70mA
Standby Battery
Type NiMh stack
