BHT-412-MM-2
Export Classification C, ECCN EAR99
5-00-00
Chapter 67
BHT-412-CR&O
BHT-412-SI-44
TB 412-87-60
FLIGHT CONTROLS
1. Disassemble pilot and copilot (if installed) collective
stick(s) to the extent necessary to remove throttle twist grips.
2. Referring to Figure 5-1, visually inspect stick tube for
cracks using a 3X magnifying glass and a bright light. Pay
particular attention to the base of the throttle slots that form the
twist grip stops.
3. If a crack is found, replace stick tube.
4. Reassemble pilot and copilot (if installed) collective
stick(s).
5. Check throttle controls for proper operation.
6. Check collective controls for proper operation.
5-8. 5000 HOUR/5 YEAR INSPECTION — PART A (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
Page 56B Rev. 23 15 DEC 2015
