Textron BOB-CAT 942209 - Yanmar Wire Harness

44
ZT 220D
Series
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
9-1 2720866 HARNESS-WIRING 1
(INCLUDES ITEMS 2, 19, 20 & 21)
9-2 148082-20 FUSE-20 AMP 1
9-3 2218089 CABLE-BATTERY 1
9-4 158135-01 SWITCH-SEAT NO 1
9-5 158136 WIRE-SEAT SWITCH 1
9-6 48030N HOUR METER ASSY 1
9-7 2198092 CABLE-GROUND 1
9-8 2721126 KEY-SWITCH W/BEZEL 1
9-9 128037 RELAY 8
9-10 2188154 MODULE-DELAY 1
9-11 2188153 SWITCH-CLUTCH 1
9-12 2721337 CLUTCH 1
(INCLUDES ITEM 27)
9-13 2188172 HARNESS-JUMPER 2
9-14 108208 SWITCH-DBL POLE 3
9-15 2720886 TEMP-GAUGE 1
9-16 2720887 TEMP-SENDER 1
9-17 2198089 LAMP HOLDER 1
(INCLUDES QTY 2 OF ITEM 18)
9-18 178092-22 LAMP 2
9-19 148082-10 FUSE-10 AMP 1
9-20 148082-30 FUSE-30 AMP 1
9-21 1003416 DIODE 4
9-22 188015 LENS-OIL PRESSURE 1
9-23 2198088 LENS-BATTERY 1
9-24 FUEL PUMP 1
(AVAILABLE THROUGH YANMAR DEALER)
9-25 48524 CIRCUIT BREAKER 1
9-26 2721059 CABLE-CIRCUIT BREAKER 1
9-27 2720949 WIRE-ASSEMBLY CLUTCH 1
9-28 38382 SWITCH-NO 1
2721543-09
FIGURE 9
YANMAR WIRE HARNESS
