5
ZT 200
Series
4. TRACTION LEVERS
a) Remove bolt A.
b) Rotate traction lever B into position
and secure with bolt A. Repeat for
the other lever.
c) Tighten all fasteners.
d) Sit on the machine. If the levers
are too long, bracket C may be
removed to make them shorter.
Ä
...
5. FINAL PREPARATIONS
– Check the engine and hydraulic oil levels. Top up with the correct oil if necessary. See engine manufactur-
ers manual for recommended grade of oil. Use fresh, clean 15W40 or 20W50 motor oil or 15W50 synthetic
motor oil for the hydraulic system.
– Remove the battery from the machine and trickle charge for several hours. Replace the battery in the
machine and make the connections, red to positive first, then black (ground) to negative.
– Read Operation and Safety Manual before starting.
– If fuel tanks have been completely emptied, refer to the bleeding the fuel system on Page 11 of this manual.
– Run engine at full RPM for 5 minutes before engaging blades to allow the engine to be fully lubricated before
load is applied.
– Check the hydrostat neutral adjustment. Neutral is set at the factory but may require readjustment if air
trapped during the initial oil fill has worked out of the system. See adjustments section later in this manual.
– Do not use the machine without an approved grass collector, the grass discharge chute or mulching plates
correctly fitted.
ASSEMBLY AND SETUP
