Textron BOB-CAT 942209 User Manual

PART NO. DESCRIPTION FIG/ITEM PART NO. DESCRIPTION FIG/ITEM
CROSS REFERENCE
ZT 220D
Series
66
2720889.7 WLDMT-RADIATOR SCREEN 11 /1
2720891.7 SCREEN-OIL COOLER 12 /4
2720949 ASSY-CLUTCH WIRE 2 /11
2720949 ASSY-CLUTCH WIRE 9 /27
2720975 SEAT-LOW PROFILE SSPNSN 13 /1
2720975-03 ADJUSTER 13 /8
2720975-04 ADJUSTER W/HANDLE 13 /7
2720975-05 CABLE ASSEMBLY 13 /21
2720994 LABEL-BOB-CAT TEXTRON SM 4 /2
2720996 S-ENG DECK W/LBL ZT220D 1 /3
2720996 S-ENG DECK W/LBL ZT220D 2 /23
2720996 S-ENG DECK W/LBL ZT220D 5 /2
2720996 S-ENG DECK W/LBL ZT220D 6 /1
2720996 S-ENG DECK W/LBL ZT220D 10 /4
2720996 S-ENG DECK W/LBL ZT220D 14 /1
2721028 S-PANEL W/BOB-CAT LABEL 10 /3
2721059 CABLE-BATT TO BREAKER 9 /26
2721060 LABEL-CONTROL PANEL 4 /6
2721076.7 WLDMT-CRADLE 15 /20
2721076.7 WELDMENT-CRADLE 3 /1
2721076.7 WELDMENT-CRADLE 14 /20
2721093 ARMREST RH 13 /2
2721094 ARMREST LH 13 /3
2721099 LABEL - FUSE 4 /16
2721126 KEYSWITCH ASSY W/BEZEL 9 /8
2721126 KEYSWITCH ASSY W/BEZEL 10 /13
2721246 DAMPENER 1 /28
2721298.7 WLDMT-CASTER ARM 61 RH 15 /22
2721299.7 WLDMT-CASTER ARM 61 LH 15 /21
2721300.7 WLDMT-CASTER ARM 52 RH 15 /17
2721301.7 WLDMT-CASTER ARM 52 LH 15 /16
2721306.7 WLDMT-CASTER YOKE 15 /2
2721307 CAP-BEARING 15 /14
2721324.7 WLDMT-BUMPER 5 /3
2721325.7 BUMPER-UPPER 5 /1
2721337 CLUTCH-ELECTRIC 2 /6
2721337 CLUTCH-ELECTRIC 9 /12
2721338.7 WLDMT-CLUTCH STOP 2 /7
2721355.7 STRAP-RADIATOR HINGE 12 /14
2721450 BELTING-HINGE 12 /15
2721489 TANK-FUEL LH BOBCAT 10 /1
2721490 TANK-FUEL RH BOBCAT 10 /2
2721530.7 BRACKET-RELAY 1 /5
2721531 GUAGE-TEMP W/ALERT 10 /44
2721570.7 PLATE-RADIATOR MTG 12 /19
2721581.7 BRKT-FUEL BLEED VALVE 10 /31
2721624.7 BRKT-RADIATOR SWITCH 11 /13
2721626 LABEL-FUEL LINE BLEED 4 /17
2721630 HOSE-AIR CLEANER 11 /20
2721646 HINGE-50.8 X 470 12 /13
2721661.7 PLATE-BACKING 12 /11
2721662 BARRIER-AIR FLOW 12 /12
2721803 S-COOLER BRKT W/LABEL 12 /21
2721806 CAP-FUEL DIESEL 3.5 10 /6
2721894 CLUSTER-WARNING LIGHT 10 /45
2721931.7 BRKT-RADIATOR SUPPORT 12 /30
2721933.7 WLDMT-SUPPORT BRACKET 12 /2
31012A ENGINE PULLEY 16 /23
32418-03.7 HANDLE-W/SLOTS 3 /17
32723.2 CHUTE-DISCHARGE MIDSIZE 16 /5
32767.7 SUPPORT-BELT 16 /47
33148-01 SPACER 2 /19
33213 ROD-SPD CTRL UPPER 6 /6
35027N ZERK FITTING 2 /16
35027N ZERK FITTING 15 /8
364152 BUSHING-1.378X1.750X1.000 11 /21
365956 DECAL 4 /18
365956 DECAL 12 /22
38020-01 CLEVIS YOKE, 3/8 PLATE 6 /29
38020N CLEVIS YOKE, 5/16 PLATE 1 /23
38020N CLEVIS YOKE, 5/16 PLATE 6 /8
38061A SPINDLE SHIELD 10 /9
38219 SPRING-TENSION 2 /20
38297 IDLER, 5 OD FLANGED 16 /19
38304-02 BRG, FLGD PLASTIC 1 /47
38304-03 BRG-FLANGED PLASTIC 2 /9
38315 NUT-SPINDLE 16 /34
38345 PUMP BDP10L-119 HYDRGR 1 /2
38345 PUMP BDP10L-119 HYDRGR 7 /14
38345-01 S-2513018 SEAL KIT 8 /48
38345-02 S-2510008 POPPET VALVE-KIT 8 /51
38345-03 S-2510027 CHECK BALL KIT 8 /52
38345-04 S-2513017 HOUSING KIT 8 /54
38345-05 S-2510011 CHRG RELIEF-KIT 8 /50
38345-06 S-2003040 HSG-CHRG PUMP 8 /6
38345-07 S-J1041008 GEROTOR ASSY 8 /7
38345-08 S-9004101-1340 O-RING 8 /8
38345-09 S-2003020 SHAFT 8 /18
38345-10 S-9007375-0038 SCREW 8 /10
38345-11 S-9007314-0810 SCREW 8 /4
38345-12 S-9007314 CYL BLOCK KIT 8 /49
38345-13 S-2513016 END CAP KIT 8 /53
38345-14 S-2003067 GASKET 8 /5
38348-01 BEARING-SPINDLE SEALED 16 /35
38369-01 ROD END BALL JOINT RH 1 /31
38369-02 ROD END BALL JOINT LH 1 /14
38371-01 BRG-NYLINER 3/8 13 /17
38382 SWITCH-N.O. 9 /28
38382 SWITCH-N.O. 11 /11
38524 KNOB-4 PRONG 3/8-16 16 /4
38540 VALVE-FUEL W/FILTER 10 /19
38542 CLAMP-DOCUMENT TUBE 10 /7
446118 LOCKWASHER-#10 10 /43
450766 SKT CAPSCREW 12-1.75X100 6 /31
46335 SHAFT ASM-ROLLER 16 /8
48016-11A S HOSE,.25IDX.50ODX26 LG 10 /23
48016-11A S HOSE,.25IDX.50ODX26 LG 10 /24
48016-11A S HOSE,.25IDX.50ODX26 LG 10 /25
