INTRODUCTION
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
3
1. Key Switch / Headlight Switch
Located on the dash panel, this switch enables the basic electrical system of the vehicle to be turned on and off by
turning the key. The switch has 3 positions, OFF, ON and Headlights. To prevent inadvertent operation of the vehicle
when left unattended, the key should be turned to the ‘OFF’ position and removed.
2. Steering Wheel
The steering wheel located in front of the driver seat is used to steer the vehicle.
3. Direction Selector
To reduce the possibility of component damage, the vehicle must be completely stopped before moving the direction
selector.
Located on the seat support panel, this lever permits the selection of either ‘F’ (forward) or ‘R’ (reverse). Vehicle
should be left in ‘F’ when unattended.
4. Choke
The choke is used to aid cold starting. See COLD STARTING section for operating instructions.
5. Horn
The horn is operated by pushing the horn button located on the floor to the left of the brake pedal.
6. Brake Pedal
Depress the lower portion of the brake pedal to slow or stop the vehicle.
7. Park Brake
The park brake is activated by pushing on the top portion of the brake pedal until it locks in place. The park brake will
release when the service brake pedal (lower portion of the brake pedal) is depressed.
8. Accelerator Pedal
With the key switch ‘ON’, depressing the accelerator pedal starts the engine. When the pedal is released, the engine
will stop. To stop the vehicle more quickly, depress the brake pedal.
9. Seat
The bench seat is designed for two occupants, one on each side of the seat.
10. Hip Restraint
The hip restraints for the bench seat are designed to help keep the occupants properly positioned in the event of
sudden vehicle position changes.
11. Engine Compartment
The engine compartment is accessed by raising the bench seat bottom.
To Next Page
