5 - 5
MAINTENANCE
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
5
To raise the entire vehicle, install
chocks in front and behind each
front wheel. Center the jack under
the rear frame crossmember.
Raise the vehicle enough to place
a jack stand under the outer ends
of the rear axle.
Lower the jack and test the stabil-
ity of the vehicle on the two jack
stands.
Place the jack at the center of the front axle. Raise the
vehicle enough to place jack stands under the frame cross-
member as indicated.
Lower the jack and test the stability of the vehicle on all
four jack stands.
If only the front or rear of the vehicle is to be raised, place
the chocks in front and behind each wheel not being raised
to stabilize the vehicle.
Lower the vehicle by reversing the lifting sequence.
WHEELS AND TIRES
A tire explosion can cause severe injury or
death. Never exceed the inflation pressure rating
on the tire sidewall.
To reduce the possibility of tire explosion, pres-
surize tire with small amounts of air applied intermittently to seat beads. Due to the low volume
of the small tires, overinflation can occur in seconds. Never exceed the tire manufacturer’s rec-
ommendation when seating a bead. Protect face and eyes from escaping air when removing a
valve core.
To reduce the possibility of severe injury caused by a broken socket when removing wheels, use
only sockets designed for impact wrench use.
DO NOT use low inflation tires on any E-Z-GO vehicle. DO NOT use any tire which has a recom-
mended inflation pressure less than the inflation pressure recommended in the owner’s guide.
Use caution when inflating tires. Overinflation could cause the tire to separate from the wheel or
cause the tire to explode, either of which could cause severe injury.
Tire Repair
Tool List Qty. Tool List Qty.
Lug Wrench, 3/4”......................................................... 1 Impact Socket, 3/4” ................................................. 1
Lug Wrench, 5/8”......................................................... 1 Impact Socket, 5/8” ................................................. 1
Impact Wrench ............................................................ 1 Torque Wrench, Ft. Lbs........................................... 1
Lug wrench and socket size for removal of lug nuts will depend on which wheel and tire assemblies are installed on
the vehicle.
Use caution when inflating tires. Due to the low volume of the small tires, overinflation can occur in seconds. Overin-
flation could cause the tire to separate from the wheel or cause the tire to explode.
View from Underside of Vehicle
