5 - 7
MAINTENANCE
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
5
LIGHT BULB REPLACEMENT
To reduce the possibility of premature bulb failure, do not touch new bulbs with bare fingers. Use clean, dry tissue or
paper towel to handle the glass portion of the bulb.
Headlight and Turn Signal
For vehicles equipped with lights mounted below cowl,
locate bulb socket on backside of light bar and turn bulb
socket a quarter turn counterclockwise to unlock and pull
out bulb. Insert new bulb and rotate socket a quarter turn
clockwise to secure.
Brake Light
To replace the brake light bulb, remove two phillips head
screws securing lens, pull the lens out of the housing.
Remove the light bulb and install a new bulb, make sure
the bulb makes good contact with the socket. Replace the
lens and reinstall the phillips head screws.
FUSE REPLACEMENT
To replace fuses, raise the seat bottom, the fuse block is
located on the fender liner on the driver side of the vehicle.
Pull out old fuse and replace with a new fuse of the same
type and size.
Marker
Light
Turn
Signal
Light
Y
R
R
G
Headlights
Marker
Light
Turn Signal
Light
