1818 Mechanical Bender
Setting Up Your Bends
Thefollowingdescribesameansforlayingoutthestartingpointsforvarioustypesofbends.Itwillgiveveryaccu-
rate measurements for heights and bend angles commonly used.
Stubs:
 1. Gotothefollowingchartwhichisforthesizeandtypeofconduityouaretobend.
 2. LookdowntotheANGLEcolumnuntilyoucometotheangleyouwanttobendto.
 3. LookatthenumbersintherowprecededbyYandpicktheonethatisdirectlyundertheheight(H)youwant.
 4. Placeamarkthisdistancefromtheendoftheconduit.
 5. Makeyourbendafterpositioningthefrontedgeofthehookonyourmark.
Offsets: (Controlling the start of the first bend)
 1. SubtracttheXdimensionforthesizeofconduittobebentfromthedesiredlength.
 2. Placeyourrstmarkthisdistancefromtheendoftheconduit.
 3. Gotothefollowingchartwhichisforthesizeandtypeofconduityouaretobend.
 4. LookdowntotheANGLEcolumnuntilyoucometotheanglesyouwanttobendto.
 5. LookatthenumbersintherowprecededbyL1andpicktheonethatisdirectlyundertheheight(H)youwant.
 6. Placeasecondmarkthisdistancefromyourrstmark.
 7. Makeyourrstbendafterplacingthefrontedgeofthehookontherstmarkandyoursecondbendafter
placingthefrontedgeofthehookunderthesecondmark.
Special Bending Information
← Y →
←
HEIGHT
ANGLE
MARK
←
←
←
←
← L1 →
← LENGTH – X →
←
HEIGHT
→
← LENGTH →
START OF
FIRST
BEND
ANGLE
BENDING
MARK 1
BENDING
MARK 2
→
→
