HE.14356_A © 11/2012
ESB 15-L
3
GB
Instruction Manual Bending Tool
authorised
copy
2. Warranty
If the tool is operated according to its intended use and the regular maintenance services are observed our war-
ranty is 24 months from the time of delivery. Worn-out parts resulting from its intended use are excluded. We re-
serve the right to rework the tool in case of a justifi ed warranty claim.
3. Description of the electric-hydraulic tool
3.1 Description of the components
The electric-hydraulic unit is a hand guided tool and consists of the following components:
Table 2 (see Picture 1)
Pos. Description Function
1 Bending head Solid 350° smoothly rotary bending head
2 Retract button button to open in case of emergency
3 LED (red) Indicator for battery charge control, tool functions and faults
4 Battery lock Slide to unlock the battery
5 Battery
cartridge
rechargeable 1,3 Ah Li-Ion battery (RAL1/BL1815)
or 3Ah Li-Ion battery (RAL2/BL1830); Optional: mains adapter NG2
6 LED (white) to illuminate the working area
7 Trigger switch to start the work procedure
3.2 Brief description of the important features of the unit
The hydraulic unit incorporates an automatic retraction which returns the piston into its starting position when the
maximum operating pressure is reached.
The tool can be stopped in the advance mode in any position and it will maintain this position until the trigger is actu-
ated again and the bending cycle is continued.
A manual retraction allows the user to return the piston into the starting position in case of an incorrect crimp.
A manual retraction stop allows the user to stop the retract at any position during the automatic retraction by pulling
the trigger.
