HE.14356_A © 11/2012
ESB 15-L
7
GB
Instruction Manual Bending Tool
authorised
copy
6. Technical Data
Weight (incl. battery): approx. 3,45 kg
Force: approx. 15 kN
Driving motor: direct-current permanent fi eld motor
Battery voltage: 18 V DC
Battery capacity: 1,3 Ah (RAL1/BL1815) or 3 Ah (RAL2/BL1830)
Charging time: 15 min. (RAL1/BL1815) or 22 min. (RAL2/BL1830)
Bending time: 5 - 8 sec.
Cycles per battery: approx. 150 cycles
Hydraulic oil: Rivolta S.B.H. 11
Environmental temperature: -10°C bis +40°C
Sound level: < 70 dB (A) in 1m distance
Vibrations: < 2,5 m/s²
Dimensions: See pic. 2
7. Putting out of operation/waste disposal
This unit is subjected to the scope of the European WEEE (2002/96/EG) and RoHS (2002/95/EEC) directives.
Information about this can be found in our home page www.Klauke.com under ‘WEEE & RoHS’.
Battery cartridges must be specially disposed of according to the EEC Battery Guideline.
Attention
Do not dispose of the unit in your residential waste. Klauke has no legal obligation to take care of their WEEE
outside Germany unless the product has been shipped and invoiced from inside your country by Klauke.
Please contact your distributer to fi nd out more how to get your tool recycled environmental friendly.
Kontaktadresse: Attention
WEEE-Abholung@Klauke.Textron.com Additional instruction manuals are available free of charge.
The part # is HE.14356.
