HE.14356_A © 11/2012
ESB 15-L
5
GB
Instruction Manual Bending Tool
authorised
copy
After having completed work the ram return into the starting position by briefl y actuating the retract button
(pic. 1.2) once which saves you battery capacity.
Attention
The working process can be interrupted at any moment by releasing the trigger (pic. 1.7).
4.2 Explanation of the application range
The following bus bar can be bent with this tool:
CU 7,1 x 16,24 mm
CU 3,4 x 20,3 mm
CU 2,3 x 12,5 mm
CU 3,78 x 8,11 mm
AL 2,15 x 8,11 mm
Attention
Use safety glasses when you work with this tool.
Attention
Es dürfen keine unter Spannung stehenden Teile gebogen werden. This is not an insulated tool.
The hand held tool is not supposed to be restrained in a vise. It is not allowed to use the tool in a stationary applica-
tion.
The tool is not designed for continued cutting operations. After a sequence of approximately
50-60 completed works
you have to make a break of 15 min. to give the tool time to cool down.
Attention
Too intensive use can cause heat damages for the tool
Attention
During the operation of electric engines sparks can occur which might ignite highly infl ammable or explosi-
ve liquids and materials.
