Page #24 background image
24
EC
Hydro
Midsize
SPECIFICATIONS
POWER UNITS
CONTROLS:
Throttle, choke, PTO switch, speed selector lever,
key switch, operator present, traction levers
(1 per wheel), parking brake.
GROUND SPEED:
0-5.2 mph Forward
0-1.7 mph Reverse
DRIVE TIRES:
16 x 7.50 Turf Saver
BRAKES:
Hydrostat provides dynamic braking
Parking brake: Mechanical on tire surface
TRANSMISSION DRIVE SYSTEM:
Belt from engine to hydrostat input shafts, hydrostatic
drive to wheels.
TURNING RADIUS:
0"
HYDRAULIC RESERVOIR CAPACITY:
1.2 Gallons (4.5
l)
POWER STEERING:
Independently controlled drive wheels.
WEIGHT:
933303 340lbs (154.2kg)
933304h
ENGINE:
Kawasaki FS541V V-Twin
STARTER:
On/Off Switch
GOVERNOR:
2850 RPM, No Load
CUTTERDECKS
CONSTRUCTION:
7 gauge steel deck welded single unit, bafed for
high velocity air ow, large discharge opening with
chute guard deector.
SPINDLES:
1" spindle shaft on maintenance free sealed ball
bearings in precision
machined housing.
CASTERS:
9 x 3.50-4 solid foam.
HEIGHT OF CUT:
adjustable from 1-3/8" to 4-5/8" (3.5-11.7 cm)
BLADE DRIVE:
industrial B section heavy duty v-belt drive (not
twisted) from crankshaft to
cutterdeck with 5" steel idlers on sealed ball bear-
ings. Pto switch on control panel controls engage-
ment of blades.
BLADE MATERIAL:
1566 alloy steel, austempered and heat treated.
CUTTING WIDTH:
36" (91.4cm)
ACCESSORIES AVAILABLE
METAL EASY DUMP GRASSCATCHER
ECO-PLATE
