rev 12/98 4 - 3 09-367
OPERATION section 4
Photo 6 - Front Transaxle selector lever
and Front Hitch Release Lever
17. Front Transaxle Range Selector Lever - See
section 4.4 for HI - LO Range Selection
18. Front Hitch Release Lever - Releases quick
hitch latch for attachments.
19. Parking Brake Lever (On left side) - Set park
-
ing brake before dismounting.
Photo 7 - Controls, Parking Brake
19
18
17
