09-367 1 - 2 rev 12/00
INTRODUCTION section 1
SPECIFICATIONS
Dimensions:
Overall Width ______44"
Overall Length _____64"
Overall Height _____49"
Wheelbase _______38"
Inside Turning Radius _ _ 46"
Weight (Linamar) ____1000 lbs.
Weight (Kohler) _____1000 lbs.
Weight (Kubota) _____1100 lbs.
Engine:
Standard________Linamar LX790
20 HP air-cooled
Optional ________Kubota D722-E Diesel 44 cu. In. (719 cc )
liquid-cooled 21 HP @3600 RPM
Optional ________Kubota WG750-E Gas 45 cu. In. (740 cc )
liquid-cooled 21 HP
Optional ________Kohler Command V-Twin
25 HP air-cooled
Drive Train:
Transmission ______Sundstrand Hydrostatic
Series 15 Pump and
2 motors
Transaxles _______Peerless 2500 Series
2-speed
SPEEDS:
Forward (Traction Type Tires) _______0-8.5 MPH (high range)
0-4.4 MPH (low range)
Reverse (Traction Type Tires) _______0-5.3 MPH (high range)
0-2.8 MPH (low range)
Steering ________Hydraulic
power steering
Parking Brake______Disc type
Tires:
Traction Type ______21x11.00-8, Rawhide
Turf Type, optional ____20x10.00-8, Turfmate
Electrical:
Starting ________12volt, Key switch
Battery_________12volt, Group 26
Fuel System:
Tank capacity ______6Gallons
FuelPump_______Diaphragm (Linamar)
Diaphragm (Kohler)
Electric (Kubota)
Specifications are subject to change without notice.
