rev 12/98 7 - 1 09-367
ASSEMBLY INSTRUCTIONS section 7
Assembly Instructions for
430 Tractor:
1. Remove unit and all parts from crate.
2. Install the wheels with valve stems facing out
-
ward and traction bar tread facing in the proper
direction. There are two right wheels and two
left wheels Tighten wheel nuts to 85 ft. lbs. Ad
-
just tire pressures. Refer to Service Schedule in
Section 5.
3. Install the seat (if removed) and connect the wir-
ing for the seat switch. It is very important to
connect this wiring for safety interlock and op-
erator presence control.
4. Install the steering wheel (if removed) and
torque the nut to 40 ft. lbs. Snap the center
cover in place.
5. Check all fluid levels. Refer to Service Schedule
in Section 5.
6. Visually inspect for loose bolts or fittings.
7. Start the unit and test drive to check all func
-
tions.
