TFI AXT-225 - Step 1

AXT-225 Deluxe Home Gym www.tu stu tness.com
15
71
126
83
*23
126
*7
Step 1
Step 1 Assembly List
Item # Description Qty.
*7 BASE FRAME 1
*23 REAR FRAME 1
71 HEX HEAD CAP SCREW Z/P 3/8-16 X 5 1/8 2
83 NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 2
126 OVAL WASHER Z/P 3/8” 4
Loosely Tighten
Loosely tighten all hardware in this step.
Loosely Tighten
70%
NOTE:
1. It is strongly recommended that 2 people participate in the assembly
of this unit.
