TFI AXT-225 - Parts List

AXT-225 Deluxe Home Gym www.tu stu tness.com
33
Parts List Continued
Item No. Description
Rev.
Part No. Qty. Item No. Description
Rev.
Part No.
Qty.
127 BNH4304
2
136 BNH2924
4
128 BNH4069
1
137 BNH2925
1
129 BNH2912
4
138 BNH3155
1
130 BNH3146
3
139
ANTIȬTWISTȱCABLE
0 UP8528 1
131 BNH3113
1
140 BNH3147
1
132 BNH2916
2
141 BNH2911
1
133 BNH3147
1
142 BNH2923
1
134 BNH3145
1
143 BNH2926
1
135 BNH2903
1
144
BNH2056 2
Item No. Description
Rev.
Part No. Qty. Item No. Description
Rev.
Part No.
Qty.
*3
ADJUSTABLEȱDOUBLEȱPULLEYȱBRACKET
0 UP7719X1 1 *23
REARȱFRAME
0 UP7745X1 1
*7
BASEȱFRAMEȱ
1 UP7739X1 1 *24
TOPȱFRAME
1 UP7868X1 1
*8
FLOATINGȱPULLEYȱBRACKET
1 UP3733X1 1 *32
TOPȱGUIDEȱRODȱHOUSINGȱ
0 UP7741X1 1
*12
FRONTȱUPRIGHT
0 UP7740X1 1 *33
WEIGHTȱSHIELDȱREAR
0 UP7762X1 1
*20
PRESSȱBAR
0 UP7743X1 1 *150
WEIGHTȱSHIELDȱFRONT
0 UP7762X2 1
*21
PRESSȱBARȱHOUSINGȱ
0 UP7748X1 1 *151
ADJUSTABLEȱDOUBLEȱPULLEYȱBRACKET
0 UP7719X2 1
AXT-225 REV1
AXT-225
Parts List
LABELȬTFIȱSERIALȱNO.ȱ2.5ȱXȱ1.5
TFIȱEMBLEMȱ2.26ȱHIGHȱXȱ2.3770ȱWIDEȱBLUEȱANDȱCHROME
LABELȬINSPECTIONSȱRECOMMENDEDȱINSPECTION…
LABELȬTFIȱSERIALȱNO.ȱ2.5ȱXȱ1.5
LABELȬNUMBERSȱ10Ȭ200ȱLBS/KGSȱ7/8ȱXȱ3ȱYELLOWȱ&ȱBLACK
LABELȬWARNINGȱATTENTIONȱUSERS!...ȱ2X1.5
LABELȬIMPORTANTȱFORȱSMOOTHȱPERFORMANCE
PRE ASSEMBLED COMPONENTS
LABELȬIMPORTANTȱFORȱSMOOTHȱPERFORMANCE...
LABELȬWARNINGȱDOȱNOTȱUSEȱFORȱCHINNING...
LABELȬCAUTIONȱCHECKȱȱPULLȬPINȱISȱFULLY…
LABELȬDANGERȱCHECKȱRETAININGȱNUT...ȱȱ1.5ȱXȱ1
LABELȬIMPORTANTȱCHECKȱCABLES
LABELȬDANGERȱDOȱNOTȱLEANȱAGAINST,ȱ1.75X2.375
LABELȬDANGERȱUSEȱTHISȱEQUIPMENTȱONLY...ȱ
LABELȬWARNINGȱKEEPȱBODY,ȱHANDS...ȱ1X2Ȭ5/8
LABELȬIMPORTANTȱADJUSTȱ
CABLEȱTENSIONȱHERE
NYLONȱINSERTȱLOCKȱNUTȱZ/Pȱ5/16Ȭ18
COLOR CHART
GRAY= SUB-ASSEMBLY PARTS
BLACK= HARDWARE
