TFI AXT-225 - Step 9 Anti-Twist Cable Routing

AXT-225 Deluxe Home Gymwww.tu stu tness.com
24
145
STEPȱ1
145
STEPȱ2
*8
145
60
*8
113
Step 9 Anti-Twist Cable Routing
Step 9 Assembly List
Item # Description Qty.
*8 FLOATING PULLEY BRACKET 1
60 FINISHED HEX NUT Z/P 1/2-13 1
113 SPLIT LOCK WASHER Z/P 1/2” 1
145 ANTI-TWIST CABLE 1
NOTE:
1. SOME PARTS CUT OUT/NOT SHOWN FOR CLARITY.
