The Fire Beam firebeam - Distance and Positioning Guidelines; What Distance?

distance & positioning guidelines
these guidelines are given as a guide only and it is important
that you refer to your appropriate governing standards at all
times.
5m
standard 5-40m beam
standard beam+40-80m reflector kit
standard beam+80-100m reflector kit
40m
80m 100m
what distance?
The standard fire beam will be suitable for distances of over 5m to 40m to the
reflector.If you require
40m to 80m you will need to use the mid range reflector
extension kit. For ranges of 80m t0 100m you will require the long range reflector kit.
5-40 metres the standard firebeam The standard firebeam comes boxed with the head unit, low
level controller, one reflector, 3mm allen key, test filter and quick start installation guide
this should be used for distances over 5m and up to 40 meters
40 - 80 metres = the standard firebeam + mid range 40 to 80m kit
for distances 0f 40 metres to 80 meters you will need to use the standard firebeam and a mid range extension kit (the mid range kit comes with a back-
ing plate and 3 extra reflectors, you will need to add the reflector from the standard kit to the mid range kit with the screws provided)
40 - 80 metres
add the reflector from the standard firebeam to the
mid range kit with the screws provided
5-40 metres
2
