Location of Controls (Top/Front)
6
5
4
3
2
1
10
11
12
9
8
13
14
7
19
18
17
16
15
23
24
26
25
22
21
20
1. Cradle
2. MASTER VOLUME Control
3. ON/OFF Button
4. MIC VOL + Button
5. ECHO + Button
6. VOCAL Button
7. BLUETOOTH Pairing Button
8. ECHO – Button
9. MIC VOL – Button
10. LIGHT MODE Button
11. Remote Sensor
12. SD Card Slot (for Record only)
13. SMC USB Slot
14. Function Indicator
15. FUNCTION Button
16. Bluetooth Indicator
17. MENU Button
18. Navigation UP 5 Button
19. Navigation RIGHT Button
20. Navigation LEFT Button
21. Navigation DOWN Button
22. ENTER/ Button
23. RECORD
n
Button
24. MIC 2 Jack
25. MIC 1 Jack
26. Lights
To Next Page
