Location of Controls (Top/Front)
1. Disco Ball
2. TFT LCD Color Screen
3. VOCAL/PAIR Button
4. FUNCTION (Monitor ON/OFF) Button
5. MENU Button
6. RECORD Button
7. DISCO BALL Button
8. ON/OFF Button
9. MIC Holder
10. EXTERNAL INPUT VOLUME Control
11. MIC 1 VOLUME Control
12. EXTERNAL INPUT Jack
13. Tweeter
14. LINE IN Jack
15. Bluetooth Indicator
16. MASTER VOLUME Control
17. Navigation LEFT

Button
18. Navigation UP

Button
19. Navigation RIGHT

Button
20. Navigation DOWN

Button
21. Remote Sensor
22. ENTER/
Button
23. LIGHT MODE Button
24. VOICE EFFECTS Control
25. MIC 2 VOLUME Control
26. MIC 2 Jack
27. MIC 1 Jack
28. USB Slot
29. Speaker/Lights
