The Singing Machine SMC2068 - Connecting Peripherals; AC Power Connection for Charging; HDMI Connection to TV

— E7 —
NOTES:
• Make all connections prior to plugging the AC adaptor into a power outlet.
• The provided AC adapter can only be used to charge the built-in rechargeable battery. Do
NOT use with other devices.
Connections
Insert the AC power cord into a
conveniently located AC outlet having
120V AC, 60Hz.
Charging the unit
Connecting the Unit to a TV
To output the casting video and
casting audio to your TV, perform
the following steps:
Plug the HDMI cable (not included)
into the HDMI Jack on the back of
the unit. Plug the other end of the
HDMI cable into the HDMI input on
your TV.
NOTES:
• This unit can be used with or without a TV, but it is highly recommended to use a TV in
order to utilize all the features.
• Also refer to the TV’s User Guide.
• Audio and mic input cannot be output to your TV.
HDMI Jack (In)
HDMI IN 1
HDMI Cable
2
Rear of External TV
HDMI Jack (Out)
