16
6. Technical data
Operating voltage: 230 V AC +10 % / –15 %
Frequency: 50–60 Hz
Standby: 0,54 W
Max switching capacity: 16 A (at 250 V, cos ϕ = 1)
Switching capacity: 2 A (at 250 V, cos ϕ = 0,6)
Min. switching capacity: 10 mA/230 V AC
100 mA/24 V AC/DC
Switch output: Switching of any phase is
permitted
Shortest switching time: 1 min
Switching accuracy: accurate to the second
Protection rating: IP 20 in accordance with EN
60529
Protection class: II in accordance with EN
60730-1 subject to designated
installation
Operating temperature: – 30 °C … + 55 °C
Power reserve: 6 years
Time accuracy (typical): ± 0,5 s/day (25 °C)
Rated impulse withstand
voltage:
4 kV
Pollution degree: 2
Software: class A
Contact: NO contact
Glow lamp load: 2600 W
Halogen lamp load: 2600 W
