Thecus N12000 series User Manual

76
Jumbo Frame Support
Enable or disable Jumbo Frame Support of the associated interface on your
Thecus IP storage.
Link Type
Select from drop down list for desired mode.
IPv4/IPv6
Click to enable IPv4/IPv6 for TCP/IP. The default is IPv4 enabled.
Mode
It has to be a static IP with the link aggregation being used.
IP
IP address of link aggregation.
Netmask/Prefix Length
Input netmask for IPv4 and Prefix length for IPv6.
Gateway
Gateway for associated link aggregation
Default gateway
It can be chosen from the drop down list of default gateway being used for
the Thecus IP storage.
Now under the networking, a “Link1” tab will appear from the network title bar.
To modify or delete LINK1, go to Link Aggregation setting page. Click on
to modify the settings or click on to delete this link aggregation. If any
ports are still available, additional link aggregation links can be created by clicking
.
Additional LAN
Other than on-board LAN port, Thecus IP storage supports additional NIC to be
added in its available PCI-e slot. For the details of additional NIC support list please
visit Thecus website.
http://www.thecus.com/sp_comlist.php
Once the additional NIC is installed into Thecus IP storage, the “Additional LANx”
will appear under the “Networking” category. Click the associated NIC to setup the
details. The screen shot below shows an example of an Intel PRO/1000 PT Quad
port installed thru a PCI-e slot in the Thecus IP storage.
