hear a click once it is securely in the hole. IMPORTANT: The knob must
be tightened clockwise so that the seat is secured and doesn’t rock or
click.
3. Try several heights until you are sure that you have found what works for
best for you.
Customizing the space between the seat and the back support
For most people, the factory adjusted space between the seat cushion and
the back-cushion support is comfortable. If not, you can customize the fit.
There are two other possible positions, which allow more space or less space
between the seat cushion and the back-support cushion. You will need the
3/16” allen wrench for this adjustment.
The two positions are closer to the back-cushion or farther away from the
back-cushion. The instructions below are for either adjustment.
1. Remove the safety screw located underneath the seat by turning it
counterclockwise.
2. Remove the seat by pulling up on the latch knob while pulling the it away
from the Theracycle.
3. Turn the seat over and remove the four bolts on the bottom of the seat
with the allen wrench, reposition in the desired holes, and replace the
bolts. Then firmly tighten the screws by turning clockwise.
4. Re-install the seat.
• Refer to page 7, instruction #13.
5. IMPORTANT: Make sure that the seat is completely secure and all screws
are tight when finished.
Adjusting the seat backwards or forwards
1. To adjust the seat forward or backwards, pull up the seat adjustment latch
to disengage. The seat adjustment latch is located below the seat on the
right-hand side.
2. Slide the seat to the desired position and then release the latch. The latch
can be positioned in one of the seven possible slots. Again, be certain this
is locked in place so there is no rocking or sound.
3. The seat is properly adjusted so when you are holding onto the
handlebars, your shoulders are slightly forward from your hips.
