THERMACUT EX-TRAFIRE 100SD - Torch Connection Procedure

EX-TRAFIRE
®
100SD
Operator Manual, Revision T-53-22
3� Torch connection – Torch TCS plug Latch with key position�
TCS latch with key
Torch TCS plug Latch
with key position
4� Torch connection – 1st step – place the TCS latch with key into the TCS power supply socket�
The TCS latch with key must be locked in the TCS socket properly with the latch nose�
TCS latch nose
