Wire Routing Instruction
Vertical Discharge
Route wires here
Figure 12e
Figure 12f
Install wire cover per Figure 12F. The 30"-wide
model does not need a wire cover.
Horizontal Discharge
Route wires here
Figure 12g
Wire cover
Figure 12h
Install wire cover per Figure 12H. The 30"-wide
model does not need a wire cover.
Wire cover
Page 10
