Thermaltake Core V71 - Product Specifications

Chapter 1. Product Introduction
Specification
Accessory
Warning and Notice
1.0
1.1
1.2
01
01
02
Contents
Chapter 2. Installation Guide
2.0
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
2.10
2.11
2.12
Side Panels Disassembly
Power Supply Unit (PSU) Installation
Motherboard Installation
5.25" Device Installation
3.5" & 2.5" HDD Installation
HDD Cage Installation
HDD Supporting Bracket Installtion
PCI Card Installation
Keyboard & Mouse Security Lock Usage
Fan Speed & Light Control Operation
Air Cooling Installation
Liquid Cooling Installation
Filter Installation
04
05
06
08
09
11
11
12
13
14
16
18
20
Chapter3 Leads Installation Guide
Case LED connection
USB 2.0 connection
USB 3.0 connection
Audio connection
3.0
3.1
3.2
3.3
21
21
21
21
Specification
Accessory
Figure
Parts Name
Cable Tie
Buzzer
8-pin Extension Cable
Screw＃6-32 x 6mm
Screw＃6-32 x 5mm
Screw＃6-32 x 32mm
Screw Ø5 x 12mm
Stand-off＃6-32 x 6mm
Screw M3 x 5mm
Screw M3 x 5mm
Nut Setter
Q'ty
4
4
10
20
32
1
5
1
4
4
1
Used for
Cable Management
Motherboard , ODD
Power
Motherboard Alarm
Power Connector Extension Cable
Case Fan
200mm x 30mm Fan
HDD
2.5" HDD
Motherboard
Stand-off
Full Tower
Radiator Support
SPCC
Front :
1 x 360mm, 1 x 420mm
Top :
1 x 360mm, 1 x 420mm
Rear :
1 x 120mm
Bottom :
1 x 240mm
Side Panel
Transparent Window
Case Type
Dimension (H*W*D) 583 x 230 x 560 mm (23 x 9.1 x 22 inch)
Material
Cooling System
Fan Support
Clearance
CPU cooler height limitation: 185mm
VGA length limitation: 310mm(with HDD rack)
480mm(without HDD rack)
PSU length limitation: 220mm (With Bottom Fan)
Front (intake) :
200 x 200 x 30 mm Blue LED fan x 2
(600~800rpm, 13~15dBA)
Rear (exhaust) :
140 x 140 x 25 mm Turbo fan x 1
(1000rpm, 16dBA)
Top (exhaust) :
200 x 200 x 30 mm Blue LED fan x 1
(600~800rpm, 13~15dBA)
Front :
3 x 120mm, 2 x 140mm, 2 x 200mm
Top :
3 x 120mm, 2 x 140mm, 2 x 200mm
Rear :
1 x 120mm, 1 x 140mm
Bottom :
2 x 120mm
1
