V100
Middle tower
SPCC
Front: 1 x 360 mm, 1 x 280 mm
Rear: 1 x 120 mm
Front: 3 x 120 mm, 2 x 140 mm
Top: 2 x 120 mm, 2 x 140 mm
Rear: 1 x 120 mm
CPU cooler height limitation: 160mm
VGA length limitation: 400mm
PSU length limitation: 170mm
Model
Case Type
Chassis Dimension
(H*W*D)
410 x 190 x 470 mm
(16.1 x 7.5 x 18.5 inch)
Material
Cooling System
Radiator Support
Fan Support
Clearance
Drive Bays
- Accessible
- Hidden
Rear (exhaust) :
120 x 120 x 25 mm fan (1000rpm, 16dBA)
5.25” x 2 ; 2.5” x 2
2 x 2.5“ or 3.5”(HDD Cage)
6
Power Supply
8
3.5"HDD
25
Motherboard/2.5"HDD
3
Stand-off M3 6.5mm
8
Movable tie
2
Thumbscrew #6-32 10mm
3
Screw Ta3 8mm
Fix Bazel
05
06
07
08
09
11
12
13
13
13
13
02
02
03
19
