DECOR 810/830
52
INSTALLATION
As curves and bends will decrease air flow capacity, extra curves and bends should be prevented.
Photo 12
Place the chimney around the body. (Photo 13)
Nail internal chimney to chimney montage plate that is
fixed to wall on its top outer part. Photo 14
Right Wrong
– – – 12 – – –
13
14
