THERMEx Decor 810 - Technical Specifications

DECOR 810/830
58
TECHNICAL SPECIFICATIONS
Table 1
IN ORDER TO USE THE COOKER HOOD EFFICIENTLY
• Use ducts of 150/120mm diameter and as few bends as possible when you make the chimney
connection.
• Pay attention to aluminum filters' cleaning periods and changing periods of carbon filters.
• Use the product at middle speed if high suction power is not necessary.
• In order to ensure that ventilation occurs correctly, windows of the kitchen should be kept clo-
sed.
TECHNICAL SPECIFICATIONS
Model 810 - 830
Feeding Voltage 220-240 V 50Hz
Lamp Power (W) 2 x 20 W
Motor Power (W) 210 W
Flow Capacity
(m
3
/h)
S 1 220
P 2 320
E 3 420
E 4 550
D 5 800
Motor Isolation Class F
Isolation Class CLASS I
