Thermo King TriPac EVOLUTION - Fuses

Specifications
36
Fuses
Fuse Amp
Rating
Component Protected Fuse Amp
Rating
Component Protected
F1 30 Starter F14 5 Heater On
F2 2 HMI Controller F15 2 Real Time Clock
F3 30 Glowplugs F16 50 System Power
F4 2 HMI Controller F17 2 Ground
F5 5 Standby Switch (Option) F18 3 Voltage Sense
F6 5 Logic Power (main controller) F19 1 Truck Ignition Input
F7 40 Fuel Solenoid F24 150 Main DPF Power (option)
F8 7.5 Engine Switch F25 10 SECM Power
F9 5 Engine Start Signal F26 1 Truck Ignition Input to SECM
F10 15 Pre-cooler Fan F28 5 Heater Power Sense
F11 25 Condenser Fan F29 200 Main Power Cable
F12 20 Evaporator Fan F30 3 Alternator Sense
F13 7.5 Compressor Clutch F90 20 Cab Heater
Specifications
36
Fuses
Fuse Amp
Rating
Component Protected Fuse Amp
Rating
Component Protected
F1 30 Starter F14 5 Heater On
F2 2 HMI Controller F15 2 Real Time Clock
F3 30 Glowplugs F16 50 System Power
F4 2 HMI Controller F17 2 Ground
F5 5 Standby Switch (Option) F18 3 Voltage Sense
F6 5 Logic Power (main controller) F19 1 Truck Ignition Input
F7 40 Fuel Solenoid F24 150 Main DPF Power (option)
F8 7.5 Engine Switch F25 10 SECM Power
F9 5 Engine Start Signal F26 1 Truck Ignition Input to SECM
F10 15 Pre-cooler Fan F28 5 Heater Power Sense
F11 25 Condenser Fan F29 200 Main Power Cable
F12 20 Evaporator Fan F30 3 Alternator Sense
F13 7.5 Compressor Clutch F90 20 Cab Heater
