Single button operation:
Functions / Display screen of the EDP
The functions of the unit can be changed and selected by pressing the operating button in
different ways.
Press and hold the operating button:
The unit cycles through the available functions (approx. once per second while the LCD display
screen is changing)
• H
p
(10) dose: default setting (blue rimmed)
• H
p
(07) dose: (disabled)
• ON: status of the EPD (on/off)
• Btn: status button-signal (on/off)
Press the operating button twice shortly ("double click"):
The current function that is indicated on the display screen is activated. Activation is only
possible with the functions ON and btn. For switching off the unit, another double click is
required.
FO50KOM27A/ Guide for use 3 As of January 2014
