IMA 40.019.003 - rev. 06 - 2011 19
English
Set the rotary switch (A) to the “3” position for
the continuous mode. The fan starts directly.
3. Set the room thermostat, if applicable.
Power up for ventilating:
1. Set the rotary switch (A) to the “1” position
(Fig. 7). The fan starts blowing.
4 OPERATION
4.1 During operation
4.2 Power down
Power down for heating:
1. Set the rotary switch (A) to the “0” position
(Fig. 7). The magnetic valve closes to stop
the fuel supply.
2. Disconnect the electric power.
Power down for ventilating:
1. Set the rotary switch (A) to the “0” position
(Fig. 7).
2. Disconnect the electric power.
5 MAINTENANCE
5.1 Maintenance table
Record the maintenance in the table at the back
of this book after each winter season.
/i
Caution
Do not switch the heater to one of the
heating positions when the fuel hose is
not connected, nor when the connected
fuel tank is empty.
Hot
Do not touch the flue with rain cover, nor
the air outlet! The flue with rain cover
and the air outlet become hot during
operation!
Caution
After you switch off the heater, the fan
still rotates. The fan cools the heater to
avoid damage caused by overheating.
The fan stops automatically.
Do not remove the plug from the socket
until the fan fully stops!
Description Period
Yearly Biennial
Check the pump for leakage, corrosion and filthiness. User
Check the pump, fans, ignition, photocell, burner, electrical installation and heat
exchanger for general condition.
Dealer
Check the fuel line for obstruction, corrosion and leakage. User
Check the fan of the burner for corrosion and filthiness. User
Check the fan for corrosion and filthiness. User
Clean the filters of the pump, magnetic valve. Dealer
Check the photocell for damage. Make sure the photocell is free from dust and
sediment.
User
Check the adjustment of the electrodes. User
Check the nozzle for dust, etc. Dealer
Clean the fuel filter with white spirit. User
Clean the heat exchanger. User
Clean the inlet and outlet. User
Check the V-belts. User
