User Manual
Technical Specifications
Power supply
24V AC/DC
Digital inputs
5 free voltage
Analogue inputs
3 NTC + 1 configurable: 0÷5V, 4÷20mA, NTC
Analogue outputs Opto-Insulated
4 configurables: 0÷10V signal, external relay driving
Relay outputs
5 x 5(2) A @ 250V SPST + 1 open collector 12Vdc 40mA max
Remote terminal
Serial outputs
1 RS485 slave with Mod_BUS communication protocol( only with adaptor)
