Thermoplan BW4c-CTM - Type Plate; Capacity Information

Overview
14 / 60 © Thermoplan AG
5.2 Type plate
u Slide outlet to the topmost position.
u Remove the grounds container.
ð The type plate is on the right side in the
interior.
1
5.3 Capacity information
Capacities – products (per
hour)
180 cups of espresso/140 cups of coffee/18 l hot water/120 cups of
cappuccino/120 cups of coffee
Electrical connection/power CTM-P-F (without refrigerator): 220-240VAC / 50/60Hz / 2700-3100W
CTM-P-F US (without refrigerator): 208VAC/60Hz/2700W
CTM-P-F RS (with refrigerator): 220-240VAC / 50/60Hz / 2750-3150W
CTM-P-F RS US (with refrigerator): 208VAC/60Hz/2750W
Water boiler pressure 1.17MPa (11.7bar)
Tap water pressure 0.2-0.4MPa (2-4bar)
Dimensions (W/D/H) CTM-P-F (without refrigerator): 490x600x645mm
CTM-P-F RS (with refrigerator): 660x600x645mm
Weight CTM-P-F (without refrigerator): 62kg
CTM-P-F RS (with refrigerator) 78kg
Climate class* –
refrigerator
5
Noise emission <70 dB
*The climate class indicates the room temperature at which the refrigerator may be operated to
achieve the full cooling capacity. The climate class is specified on the type plate [Type plate }
14]. Climate class 5 corresponds to a room temperature of 10°C to 43°C. Refrigerator must not
be operated outside of the specified room temperature.
