User’s manual User’s manual
GB
53
Vertical model
1 2
Place the wall-mounting frame on
the oor. Mark the drilling points A.
These points give the position of the
lower attachments.
Lift the wall-mounting frame making
the previously marked points coincide
with drilling holes A.
Mark the 2 drilling points B using a pen.
You will then have marked the 4 drilling
points.
3
Drill the 4 holes and insert the appropriate inserts for your wall (for example
plasterboard, concrete).
Put the wall-mounting frame into place and screw it into position.
NOTE: For a vertical radiator, remember to leave packing under the radiator until it has
been put into position on the wall-mounting frame.
Dimensions and weights of radiators
Horizontal model Vertical model
Power(W)
750 1000 1250 1500 2000 1000 1500 2000
Width (mm) 487 635 783 931 1153 458
Thickness (mm) 145 150
Height (mm) 607 1161 1383 1605
Weight (kg) 15 21 27 30 40 26,2 28,4 38
1.4 - Connect the radiator
The radiator must be powered at 230V 50 Hz.
The radiator power supply must be connected directly to the network behind the omni-pole
breaking device with a contact opening distance of at least 3 mm without an intermediate
switch (clock, mechanical and static relay, ambience thermostat, etc).
The connection to the mains power supply will be made using a 3-wire cable (Brown =
Phase, Blue = Neutral, Black = Pilot wire) through a connection box. The connection box
must be installed at least 25 cm above the oor in wet rooms like kitchens, the bathrooms.
The installation must be provided with a circuit breaker type protection device.
Connection to the earth is prohibited. Do not connect the pilot wire (black) to the earth.
The manufacturer, his after sales service or a similar qualied person must replace the
power supply cable if it is damaged, so that the work can be done safely.
The power supply cable must be put back into position and fixed with the plastic
flange to hold the thermostat in position. There is a risk of electrical danger if this
operation is not respected.
If the pilot or piloted radiator is protected by a 30mA differential protection device (e.g.
bathroom), then the power supply to the pilot wire connected onto this differential switch
will have to be protected.
Pilot wire connection test
You can connect the pilot wire if your house is tted with a programming unit, or a power
manager.
