Operating of the Inverter
●
Peak time discharge
Peak time discharge mode
Automatic power regulation
*Peak time discharge power(500-10000W)
３０００
The peak time discharge setting is only effective when the user selects the peak shaving
and valley filling mode. During the peak time, the default setting is that the system automat-
ically adjusts the discharge power according to the household power detected by the smart
meter; If the smart meter is not installed, the user can select a fixed discharge power
according to the approximate power consumption.
●
Battery backup mode charging setting
Charging with grid in storage mode
*Storage mode charge SOC(20-100%)
４０
*Storage mode charge power(500-10000W)
４０００
The battery backup mode charging setting is only effective when the user selects the
battery backup working mode. You can set whether to turn on the mains power to charge
the battery, and the charging power and battery charging cut-off SOC.
23
Trouble Shooting
4 Trouble Shooting
This part introduces the common fault and solving steps,provides troubleshooting
methods and skills to the user, and helps the user identify and solve some common faults of
the inverter.
Protection
Description
Recommended solution
code
Check the configuration of the PV
P001
PV over voltage protection
panels
P002
P003
P004
Battery over voltage protection
Insulation resistance low
Leakage current high
Check if battery volt larger than 600V
Check the insulation of PV panels
This error will reset itself.
P005
P006
Over temperature protection
Bus voltage unbalance
The inverter will recover automatically
when the temperature gets lower.
P007
P008
Bus voltage high
Bus voltage low
The inverter will recover automatically.
Check the connection of AC side.Make
P009
P010
P011
P012
P013
P019
P020
Grid and EPS are reversed
Grid relay open-circuit
Grid relay stick
On-grid mode bus soft start fault
MCU communication fault
Battery SOC low in on-grid
mode
Battery SOC low in EPS mode
sure the grid and EPS load are
connected to the ports on the inverter
correctly.
Shut down and restart .If it still can't be
auto-recover, please contact the
service.
Battery discharged to low level, it will
recover after charged automatically
P021
Battery voltage low
24
