Technical Data
Technical Data
5 Technical Data
Model EPH4KTL EPH5KTL EPH6KTL EPH8KTL EPH12KTEPH10KTL L
Input(PV)
Max PV Power 5500W 6500W 7500W 9500W 11500W 13200W
Max PV Voltage 1000Vd.c
MPPT voltage range 200~850Vd.c
Max input current/per string 13A/13A
Number of MPP trackers
Number of input string
2
1
Battery Input
Battery Type Li-Lon
Battery voltage range 130~700V
Max charge/discharge current 25A/25A
Charge strategy for Li-lon Battery Self-adaption to BMS
AC Output (On-Grid)
AC nominal power 4000VA 5000VA 6000VA 8000VA 10000VA 12000VA
Max AC apparent power 5000VA 5500VA 7000VA 8800VA 11000VA 13200VA
Max output current 8 10 12 15 17 20
Nominal AC output 50/60Hz;400/350
AC output range 45/55Hz;280~490Vac(Adj)
Power factor 0.8leading~0.8laging
Harmonics <3%
Grid type 3W/N/PE
Three-phase unbalance output 0~100% 0~80%
AC Output Back-up
Max AC apparent power 4000VA 5000VA 6000VA 8000VA 10000VA 10000VA
Norminal Output Voltage 400/380
Norminal Output Frequency 50/60
Output THDV (@Linear Load) <3%
27
Efficiency
Max conversion efficiency 98.0% 98.0% 98.2% 98.2% 98.2% 98.2%
European efficiency 97.3% 97.3% 97.5% 97.5% 97.5% 97.5%
MPPT efficiency 99.9% 99.9% 99.9% 99.9% 99.9% 99.9%
Safety and protection
DC reverse-polarity protection yes
DC breaker yes
DC/AC SPD yes
Leakage current protection yes
Insulation Impedance Detection yes
Residual Current protection yes
Output short circuit protection yes
Bat reverse connection protection yes
General Parameters
Dimensions (W/H/D) 548*444*184mm
Weight 27kg
Operating temperature range
-25
~+60
Degree of protection IP65
Cooling concept Natural convection
Topology Transformerless
Display LCD
Humidity 0~95%,No condensation
Communication GPRS/WiFi
CAN/RS48BMS communication 5
Meter communication RS485
