4 Installation
Setup and installation of the pads and pedals are described in detail in the included setup
guide. Finally, check that all connecting cables between the pads and the drum module are
connected correctly.
Connect the supplied power adapter to the ‘POWER’ input on the rear panel of the drum
module. Then insert the mains plug into a mains wall outlet.
Connect the supplied sub-D plug of the pad connector cable to the sub-D input socket on the
rear panel of the drum module.
Connect your computer (Windows Vista/XP®, Mac) to the USB connection on the rear panel of
the drum module.
Connect the inputs of your amplifier or powered speaker to the ‘LINE OUT’ output jack on the
rear panel of the drum module.
Setup, connecting pads and
pedals
Connecting the power supply
Connecting the pads
Connecting USB devices
Connecting audio devices
