When the button is pressed, the indicator of
the button lighter.
The LED display 001 (default command), you
can select MIDI CTRL information by the numeric
button , the [ + ] button or the [ - ] button and
¡XXX,¡ will displayed on LED. You can set 131
MIDI command (0 £130), the default number is 1.
21
Command
VOICE
STYLE
SONG
The command you select is shown on the LED .
(Once you set 128,”Cn”will be displayed, you
set 129, “Dn” will be displayed, you set 130,
“En” be displayed), you can select number
allowed circlularly by pressing the [ + ] button
or the [ - ] button;While setting number with the
numeric button,after you press the first number,
the command indicator flashes and wait for press
the second number, finish pressing the second,
if still allow press the third number, the indicator
continues to flash, waiting for press the third
number, when you finish pressing the third
number, it will stop flash. If you does not press
any button in 2 seconds , it will exit the number
setting status automatically.
number
standard MIDI control(BN)
0｣127
program change(CN)
128
129
130
command
channel pressure(DN)
pitch bend(EN)
VOICE
STYLE
SONG
VOICE
STYLE
SONG
VOICE
STYLE
SONG
127
128
129
VOICE
STYLE
SONG
130
If the number you set is from 0 ｣127 , that represent as the DATA1 of Bn order, and the value of
DATA2 can be set by pressing [VALUE] button.
If the number you set is 128,that means Cn command be selected, the value of DATA can be set by
pressing the [VALUE] button .
If the number you set is 129, that means Dn command be selected,the value of DATA can be set by
pressing the [VALUE] button .
If the number you set is 130, that means En command be selected, the value of DATA can be set by
pressing the [VALUE] button .
When the value you set is 0H, that means to bend the note down to the lowest,
When the value you set is 40H, that means to bend the note to the normal value;
VOICE
STYLE
SONG
VOICE
STYLE
SONG
3.
1.
2.
